Parameters |
Quantity |
|
|
OPERATING |
||
|
Max. initial diamete, mm |
300 |
|
|
Grade of formation for drilling |
12 |
|
|
Max drilling depth, m |
200 |
|
|
Dimensions, mm |
||
|
- Length - Width - Height |
3100 1220 1700 |
|
|
Mass, kg |
1800 |
|
|
SWIVEL |
||
|
Type |
Hydraulic oil motor with mounting group |
Reducing gear box |
|
Rotative moment, (Нм) |
1300 |
2200 (optionally till 4400) |
|
Rotation speed, (sev/min) |
||
|
I gear II gear |
240 (optionally till 630) |
0-330 0-165 |
|
MAST |
||
|
Type |
Chain drive |
Hydrocylinder |
|
Pulling force, (kg): |
||
|
- up - down |
2000 2000 |
5000 3000 |
|
Carriage movement, (mm) |
1000-3500 |
1680, 2200 |
|
Speed, m/sec |
0,43 |
0,42 |
|
HIGH-PRESSURE PUMP STATION |
||
|
Type |
Diesel |
|
|
Power, hp |
80 |
|
|
CHASSIS |
||
|
Type of crawlers |
rubber-metal |
|
|
Width of crawler, mm |
230 |
|
|
Speed, km/h |
6 |
|
|
OPTION MODULE |
||
|
Hydroclamp of drilling pipe |
optionally |
|
|
Hydroclamp of casing pipe |
optionally |
|
|
Hydraulic casing oscillator |
optionally |
|
|
Mechanical outriggers |
optionally |
|
|
Hydraulic outriggers |
optionally |
|
|
Wrench |
optionally |
|
|
Anchoring system |
optionally |
|
|
Mud Pump NB-200/80 |
optionally |
|
